InBio260

thumbnail 2

InBio260 IP-Based Biometric Access Control Panel

InBio260  Datasheet  Datasheet

InBio260 is a project oriented high-end product line with unique features such as embedded fingerprint verification and advanced access control functions, which can be managed by TCP/IP communication thru LAN or WAN networks. The InBio260 are the perfect match for ZK Bio Security web based software platform to provide a full featured biometric security solution. In combination with the FR1200 RS485 reader, the panels can authenticate users under multiple verification modes such as fingerprint, card and password for a higher security level.

Truly Internal Biometric Identification

  1. InBio carries out the matching of fingerprints on the panels. The FR Series of readers transmit fingerprint templates to InBio vis RS485 for fast and accurate matching with templates stored in the database. Wiegand inputs are also provided for traditional RFID readers.

More than Door Control

  1. Access additional control and interface. After programming, auxiliary relays can be functioned as lights, alarms and intrusion detection panels. Extra locking devices or gate controllers can be accessed.

Communicaiton

  1. InBio controllers can be installed easily on your network and support both TCP/IP and RS-485 communication. Auto-discovery tool allows setting and modification of network parameters directly and easily.

Options

  1. InBio controllers come in 3 sizes to suit project needs and reduce the cost of unused capacity. 1-door, 2-door, and 4-door models can be mixed and matched in an optimized system architecture.

Capacity

  1. Support up to 3000 fingerprint templates, 30,000 badge users and store up to 100,000
    events and transactions. Data is preserved if power is lost. Controller continues to operate if network connection is interrupted.

Advanced Access Control Built-In

  1. Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and Auxilary input/output linkages are built into controller firmware.

Lowest Total Cost of Ownership

  1. Save cost. Controller firmwares can be upgraded without any advanced tools. New
    features can extend and expand the value of your investment.







 Full Specifications

Number of Doors Controlled

2 Door

Number of Readers Supported

8 (4 RS-485 Reader, 4 26-bit wiegand reader)
Types of Readers Supported 26-bit Wiegand and RS485 FR Series Reader
Number of Inputs 4 (2-Form C Relay for Lock and 2-Form C Relay for Aux Output)
Card Holders Capacity 30,000
Fingerprint Capacity 3000 (Optional 20000)
Log Events Capacity 100,000
Package Weight 3.6kg
Communication TCP/IP and RS-485
Package Dimension 350(L)×90(H)×300(W)mm
CPU 32 bit 400MHz CPU
RAM 32M
Flash Memory 128M
Power 9.6V-14.4V DC
Operating Temp 0°-45 °C
Operating Humidity 20% to 80%
